Deep SMC Infrastructure | Sheet Metal Manufacturing Facility India

Our organization maintains a world-class infrastructure with advanced engineering machinery, skilled professionals, and manufacturing capabilities suitable for precision sheet metal, CNC operations, and modern fabrication processes.

AMADA Punch Press Machine

Press model	EMZ3510NT / EMK3510NT, EMZ3610NT / EMK3610NT
Press capacity	300 kN (30.59 metric tons or 33.7 U.S. tons) 300 kN (30.59 metric tons or 33.7 U.S. tons)
Tool storage	45 or 58* stations (45A) 45 or 58* stations (44I) 58 or 70*** stations (24I)
Max. sheet size	1270 × 5000 mm (50 × 196.85") 1525 × 5000 mm (60 × 196.85")
Max. sheet thickness	3.2 mm (0.126”) 3.2 mm (0.126”)
Max. sheet mass	50 kg (110 lb) at F1 150 kg (330 lb) at F4 50 kg (110 lb) at F1 150 kg (330 lb) at F4
Y-axis travel	1270 mm (50”) / 1525 mm (60”)
X-axis travel	2500 mm (98.43”) / 2500 mm (98.43”)
Punching accuracy	±0.1 mm (0.004")* ±0.07 mm (0.003")** ±0.1 mm (0.004")* ±0.07 mm (0.003")**

PUNCHING MACHINE (Trumpf TruPunch 1000)

Make: TRUMPF (Manufacturer: USA)
Capacity: (Bad Size : Up to 1250 X
2500,Capacity: 16 Tone)
Mild Steel: Up to 6MM thickness

TRUMPF Turbolaser 1030

Machine construction with a TruCoax 2.5 KW diffusion cooled RF laser resonator
Cost-effective
Productive Laser Cutting system in a small footprint.
Requires half of the floor space of a typical 5 x 10 foot machine
The laser cutter features 3-axis flying optics for high speed and accuracy: an X-axis working range of 120 in. and Y-axis of 60 in. with a maximum simultaneous XY speed of 3340 inches per minute.
Laser Cutting, Turret Punching, Metal Enclosure, Lab Furniture. The TruLaser 1030 will cut a maximum thickness of 5/8 in. mild steel.
The easy to use HMI features a touch panel located right on the machine and an integrated programming tool even operators with no Laser Cutting experience are able to program the machine to achieve outstanding results almost instantly.

Accurpress Press Brake 520032 (200 T x 3200 mm)

For accurate and perfect bending
Any kind of precision bending for critical parts
Very fast and time saving

Sheering with Capacity of 2500 Width x 6 MM

CNC EDM (Wire Cutting)

CNC WIRE CUT EDMS (JOB MASTER D-LITE)

Particulars	Unit	Job Master D -lite
Table Size	mm	630 x 470
Work-tank Internal Dimensions	mm	800 x 650
Main Table Travel X,Y	mm	400 x 300
Auxiliary Table travel U,V	30	80 x 80
Z-Axis Travel (Max.Thickness)	mm	250
Job Admit	mm	245
Maximum Work-piece weight	Kg	300

CNC TURNING CENTERS (DX 200 – 5A)

Particulars	Unit	DX 200 – 5 A
Swing Over Bed	mm	500
Std.Turning Dia.	mm	250
Max.Turning Dia.*	mm	365
Max.Turning Length*	30	500
Accuracy Repeatability	mm	0.005

VERTICLE MACHINING CENTERS (RX 20)

TECHNICAL DATA

Particulars	Unit	RX 20
Table Size	mm	1000X530
X-Axis Travel	mm	820
Y-Axis Travel	mm	510
Z-Axis Travel	mm	510
Distance. From spindle face to table top	mm	150-660
Accuracy Repeatability	mm	0.005
